1

Proper installation is the first step to operation. We recommend that your refrigerator or freezer be installed by a Victory
authorized service technician.

Receiving

Prior to shipping, all Victory products are factory tested for performance and thoroughly inspected to ensure they are
free of any defects. Upon receipt, carefully examine the unit for any damage that may have occurred during shipping
and delivery. Any damage, discrepancies, shortages or overages should be noted on the carrier's Bill of Lading and
a freight claim must be filed immediately with the carrier. If damage is noticed after receipt, contact the carrier's local
terminal and file a freight claim. In either case, it is important that all original cartons, crates and interior packaging
material are saved until inspection has been made with the delivering carrier
.

Uncrating

WARNING: Never lay your refrigerator or freezer down on either its back, front or sides. This causes compressor oil
to enter the refrigerant lines which can damage the compressor at start-up. If the unit is laid down, it must be set upright
for a minimum of 24 hours before starting the compressor. Failure to adhere to the above recommendation will void
the warranty.

Tools Needed : 3/4” Box Wrench, Adjustable Wrench, Level, Flathead Screwdriver, Box Cutting (or Carpenter) Knife

1. Take off the cardboard top capping by removing all clear tape and staples with a flathead screwdriver. Also remove
all staples at the bottom of the cardboard carton and skid.

2. Starting from the top of the cardboard carton, carefully take a box cutting knife and try to make one continuous cut
until you come to the wooden skid. Remove the cardboard carton from around the cabinet and discard.

*Note: An additional clear, plastic, protective wrap is applied directly to the exterior of all cabinets with glass doors.

3. Move cabinet as close to final location as possible before removing skid.

4. Remove the shipping skid by tipping the cabinet forward. Remove the shipping bolts with 3/4” box wrench while
the cabinet is held in one direction. Repeat this procedure while the cabinet is held in the opposite direction.

WARNING: The cabinet must be blocked and secured when removing the shipping skid.

5. Remove protective vinyl coating from all interior and exterior surfaces.

Roll-In or Roll-Thru Refrigerator/Freezer Location

Consider the following when selecting a location for your refrigerator or freezer:

1. Clearance - There must be a minimum clearance of 12” between the top of the refrigerator or freezer and the
ceiling.

2. Floor Load - The floor on which the cabinet will rest must be even/level, free of vibration and strong enough to
support the combined weights of the cabinet plus the maximum product load.

3. Ventilation - The air cooled, self-contained refrigerator or freezer requires a sufficient amount of cool, clean air.
Avoid placing the refrigerator or freezer near heat generating equipment such as ovens, ranges, heaters, fryers,
steam kettles, etc., and out of direct sunlight. Avoid locating the self-contained refrigerator or freezer in an
unheated room, or where the room temperature may be below 55°F.

Roll-In or Roll-Thru Refrigerator/Freezer Installation

*IMPORTANT: The floor where the new roll-in/roll-thru cabinet is to be permanently located must be a level, flat

surface prior to installation. Failure to properly level and install your equipment can void equipment

warranty!

*Notes: (a) If it is necessary to move the roll-in/roll-thru cabinet after taking off the skid, remove all doors and carefully

push the cabinet at a point of no more than 36" (inches) from the bottom to avoid damage.

(b) It is an NSF requirement that roll-in/roll-thru models are sealed to the floor upon installation.

(c) If required, the procedure for setting and grouting the two section model is within this section and

also applies to one and three section models. For reasons of clarity, the illustrations are shown without

doors on page 2.

Step 1: Locate roll-in/roll-thru model in exact position in which it is to be permanently set.

Step 2: Level unit, inserting metal shims under unit where required. It is important that an accurate carpenters level be

used when leveling cabinet. See Figure 1 on next page.
