P/N J0SSAP11 J0SSAP12 J0SSAP13 J0SSAP14
Frequency bands 6/7/8/10/11 GHz 10/11/13/15/17 GHz 17/18/23/24 GHz 24/26/30/32/38 GHz
Frequency range 5.925 - 12.000 GHz 10.000 - 18.000 GHz 17.000 - 24.300 GHz 24.000 - 40.000 GHz
Input power range -105 dBm to -40 dBm -100 dBm to -40 dBm
Max input power 0 dBm 0 dBm
RBW (Resolution
bandwidth)
1 MHz 1 MHz
Span 100 MHz to full bandwidth 100 MHz to full
bandwidth
Sweep speed 0.5s @ 100 MHz Span 0.5s @ 100 MHz Span
Guaranteed accuracy +/- 3 dB +/- 3 dB
Input 50 ohm SMA (f) 50 ohm 2.92 mm (f)
Interface mini USB 2.0 (1.1) mini USB 2.0 (1.1)
LED indication when charging when charging
Battery 2380 mAh Polymer Lithium-ion 2 x 2380 mAh Polymer
Lithium-ion
Battery life up to 4h up to 3h
Operating temperature -15ºC to +40ºC / 5ºF to 104ºF -15ºC to +40ºC / 5ºF to
104ºF
Dimensions 128 x 81 x 24 mm / 5.04 x 3.2 x 0.94 in 130 x 81 x 28 mm /
5.11 x 3.2 x 1.1 in
Weight 0.3 kg / 10.6 oz 0.4 kg / 14.11 oz
Easy In band, out of band, co-channel, adjacent
channel interference detection
Overwrite function allows easy Multipath
detection
Power In Band function for signal power
measurements
Use previously saved file as reference for
real-time radio signal comparison
Max Hold Trace mode guaranties precise
antenna alignment on main lobe
Verify radio signal according to radio
configuration and specification
