background image

9

CD PLAYER TROUBLESHOOTING

Problem

Does not operate

No power to unit

Speakers not operating

Not all speakers
o p e r a t e

Blows fuses

CD skips too much

ERROR 1

ERROR 2

Possible Cause

No power to yellow or red wire; Inline fuse
b l o w n

Inline fuse blown

Speaker harness not connected

Incorrect splices or connections; Speaker wires
shorting to chassis ground or to each other

Power wire shorting to ground; Speaker wires
shorting to ground; Incorrect/too small a fuse

Receiver mount is not solid or backstrap is not
s e c u r e

The disc is not loading or ejecting properly

An error in the laser reading the disc Ejec
the disc

Corrective Action

Check connection with test light; check vehicle
fuse with test light; Replace fuse

Replace fuse

Connect speaker harness; check speaker wires

Check all splices and connections; check splices
and insulate all bare wires

Make sure wire is not pinched; Install fuse of
correct rating

Check mounting and backstrap, and tighten if
n e e d e d

Reload or press the Eject button; check the
condition of the disk or try another disk

Make sure it is clean, undamaged, and loaded
correctly; reload and check or try another disc

Visit www.asaelectronics.com for technical assistance

Insert CD
With the label surface facing up, gently insert the disc into the slot until the soft-loading
mechanism engages and disc play begins. "S-CDP" will appear in the display momentarily, and
the CD icon will become animated. "CDP" will appear in the display momentarily with the track
number and elapsed time.

Note: The unit is designed for play of standard 5" (12 cm.) compact discs only. Do not
attempt to use 3" (8 cm.) CD singles in this unit, either with or without an adaptor, as
damage to the player and/or the disc may occur. Such damage will not be covered by the
warranty on this product.

Eject CD
Press the eject button to stop CD play and eject the disc. The unit will change to radio operation.
If the disc is not removed from the unit within 15 seconds, the disc will be reloaded and "SCDP"

will reappear in the display.
Track Select
Track select features are used to quickly access the beginning of a particular track. Press the up
or down tuning button to move forward (up tuning bottom) or backward (down tuning button) on
the disc to locate the desired track. Track numbers will appear
in the display as they are accessed.
Fast Forward

and Fast Reverse

Press and hold the up or down tuning buttons to fast forward or fast reverse a track. During
either function, the elapsed time will appear on the display. Release the button to resume
CD play.
Pause
Press PAUSE to freeze disc play. "S--PAUSE" will appear in the display for five seconds. Press
PAUSE again to resume disc play.
Scan
During disc play, press SCN to play the first 10 seconds to each track on the disc. When the
desired track is reached, press SCN again to end the scan function and play the selected track.
The scan function will also be canceled by activating the repeat or shuffle functions.
Repeat (RPT)
Press RPT during disc play to continuously repeat the selected track. "S--RPT" will appear in the
display for five seconds. Press RPT again to stop repeating, and regular play will resume. The
repeat function will also be canceled by activating the scan or shuffle functions.
Shuffle (SHF)
Press SHF during disc play to play all tracks on a CD in random, shuffled order. "S--SHF" will in
the display for five seconds. Press SHF again to stop random play, and regular play will resume.
The shuffle function will also be canceled by activating the scan or repeat functions.

8

CD PLAYER OPERATION
