Model # DUB1000 DUB1200 DUB1500
Ported
Air Space (Cu. Ft.) 0.65 1.3 1.6
Port Size (Inches) 2 x 6.8 3 x 7.25 4 x 10.5
Port Vel. (%) 34.63 24.61 25.65
-3dB (Hz) 35 35 38
Tune Freq. (Hz) 40 39 40
Sub Disp. (Cu. Ft.) 0.15 0.2 0.25
Port Disp.(Cu. Ft.) 0.01 0.026 0.071
Total Vol. (Cu. Ft.) 0.75 1.5 2
Ported
Air Space (Cu. Ft.) 1.35 2.3 2.65
Port Size (Inches) 3 x 8.5 4 x 7.25 4 x 7.5
Port Vel. (%) 16.06 14.27 23.06
-3dB (Hz) 30 31 32
Tune Freq. (Hz) 36 38 35
Sub Disp. (Cu. Ft.) 0.15 0.2 0.25
Port Disp.(Cu. Ft.) 0.031 0.047 0.048
Total Vol. (Cu. Ft.) 1.5 2.5 3
Ported
Air Space (Cu. Ft.) 2.35 3.7 3.5
Port Size (Inches) 4 x 8 (2) 4 x 11 (2) 4 x 11.25
Port Vel. (%) 9.55 7.22 11.97
-3dB (Hz) 30 30 30
Tune Freq. (Hz) 36 37 35
Sub Disp. (Cu. Ft.) 0.15 0.2 0.25
Port Disp.(Cu. Ft.) 0.053 0.12 0.153
Total Vol. (Cu. Ft.) 2.5 3.5 4
EBP 80 48 50
Model # DUB1000 DUB1200 DUB1500
Sealed
Minimum (Cu. Ft.) 0.25 0.5 1
Maximum (Cu. Ft.) 0.75 1.5 3.5
SPL (dB) 83.8 85.9 88.5
Space Saver Bass Design
The larger a sealed box is, the lower the sub will play, but the less power it will handle. The smaller a sealed box is,
the higher the frequency the sub will play, and the more power it will handle.
All sealed boxes already include the displacment for the subwoofer. NR = (Not Recommended)
DUB Box Specifications
Remember to build your box to the total volume, not just air space, as total volume includes all displacement.
An EBP of less then 45 is SUGGESTED for only a sealed box and greater then 65 for a ported box.
All ports listed are circle ports unless otherwise stated. Surface area of a circle port = (3.14) X (radius) (squared)
Ultimate SPL Bass Box
(not designed for competition use)
Everyday Bass Performer
A port velocity of 20% or under is good for everday use and 5% or under for SPL competition . Port velocity
translates to port noise, so the lower the number, the less port noise you will incur.
07
Box Parameters
