PX2858013-00 Rev. e 06/13 3
Data Sheet
Fibre Channel Specifications
Negotiation
• 8/4/2Gbps auto-negotiation
IOPS
• 200,000 initiator and target IOPS per port
Class of Service
• 2 and 3
Topology
• FC-aL, FC-aL2, point-to-point, switched fabric
Protocols
• FCP-3-SCSI
• FC-tape (FCP-2)
Cable Distances
Multi-Mode Optic
Cable type and Distance (m)
Rate OM1 OM2 OM3
2Gbps 150 300 500
4Gbps 70 150 380
8Gbps 21 50 150
PCI Express Interface
Compliance
• PCI express Base Specification rev. 2.0
• PCI express Card electromechanical Specification
rev. 2.0
• PCI Bus Power Management Interface Specification
rev. 1.2
• PCI hot Plug Specification rev. 1.0
Physical and Electrical
• PCIe x8 physical connector
• StarPower link training
– Maximum x4 lanes for Gen2 rate
– Maximum x8 lanes for Gen1 rate
Connectivity
Ports
• QLe2560: single 8Gbps Fibre Channel
• QLe2562: dual 8Gbps Fibre Channel
• QLe2564: quad 8Gbps Fibre Channel
Host Bus Adapter Specifications
Airflow
• No airflow required
Power Consumption
• QLe2560: 5.5 Watts (typical)
• QLe2562: 6.2 Watts (typical)
• QLe2564: 13 Watts (typical)
Form Factor
• QLe2560/QLe2562
– Low-profile PCIe card (6.6in. × 2.54in.)
• QLe2564
– Full-height PCIe card (6.6in. × 4.376in.)
Temperature
• 0°C to 55°C (operating)
• –40 to 70°C (non-operating)
Relative Humidity
• 10% to 90% (operating, noncondensing)
• 5% to 93% (non-operating, noncondensing)
RoHS Compliance
• RohS 6
Tools and Utilities
Management Tools
• QConvergeConsole: a unified management tool (GUI
and CLI) for adapter configuration and management
Device Utilities
• Utilities for flashing bootcode
• Linux SuperInstaller—Driver and Management tool
Installer and Linux tools
Boot Support
• BIOS, FCode, eFI
APIs
• SNIa hBa aPI V2, SMI-S, FDMI
Platform/Operating System Support
Hardware Platforms
• Ia32 (x86), Ia64, Intel 64
• aMD Opteron™ 64
• Sun ® SPaRC ®
Operating Systems
• For the latest applicable operating system information,
see
http://driverdownloads.qlogic.com .
Agency Approvals—EMI and EMC
US/Canada
• FCC Rules, CFR title 47, Part 15, Subpart B: 2006
Class a
• Industry Canada, ICeS-003:2004 Class a
Europe
• CISPR 22:2005 (amds. a1:2005, a2:2006)
• eN55022:2006, Class a (amd. a1:2007)
• eN55024:1998 (amds. a1:2001, a2:2003)
• eN6100-3-2:2006
• eN6100-3-3:1995 (amds a1:2001, a2:2005)
New Zealand/Australia
• aS/NZS;CISPR 22:2006 Class a
Japan
• VCCI 2007-04 Class a
Korea
• KN22, KN24 RRL Class a
Taiwan
• CNS 13438:2006 Class a
Agency Approvals—Safety
US/Canada
• UL60950-1:3-2007 (2nd edition)
• CSa C22.2 60950-1; 3-2007 (2nd edition)
• Class 1 Laser Product per DhhS 21CFR J
• Use only with listed Ite or equivalent.
Europe
• tUV eN60950-1:2006+a11 (2nd edition)
Ordering Information
• QLe2560 (single port)
– Ships in an individually packed box with a standard-
size bracket and a spare low-profile bracket.
– Ships with SR optical transceivers installed
• QLe2562 (dual port)
– Ships in an individually packed box with a standard-
size bracket and a spare low-profile bracket.
– Ships with SR optical transceivers installed
• QLe2564 (quad port)
– Ships in an individually packed box with a standard-
size bracket
– Ships with SR optical transceivers installed
