Host Bus Interface Specifications
Bus Interface
• PCI express Gen3 x4, Gen2 x8 (x8 physical connector)
Host Interrupts
• INtx and MSI-X
Compliance
• PCI Express Base Specification, rev. 3.0; PCI Express
Card Electromechanical Specification, rev. 2.0; PCI Bus
Power Management Interface Specification, rev. 1.2
Fibre Channel Specifications
Throughput
• 16Gbps full-duplex line rate per port (maximum)
Logins
• Support for 2,048 concurrent logins and
2,048 active exchanges
• expandable to 16K concurrent logins and 32K active
exchanges
Port Virtualization
• NPIV
Compliance
• SCSI-3 Fibre Channel Protocol (SCSI-FCP), Fibre
Channel Tape (FC-TAPE) Profile, SCSI Fibre Channel
Protocol-2 (FCP-2), Second Generation FC Generic
Services (FC-GS-2), and Third Generation FC Generic
Services (FC-GS-3)
Tools and Utilities
Management Tools and Device Utilities
• QConvergeConsole: a unified management tool
(GUI and CLI) for Fibre Channel/FCoe, iSCSI, and
networking
Boot Support
• BIOS, UeFI, FCode
APIs
• SNIa hBa aPI V2, SMI-S
Operating Systems
• For the latest applicable operating system information,
see
http://driverdownloads.qlogic.com .
Physical Specifications
Ports
• QLe2670: single 16Gbps Gen 5 Fibre Channel
• QLe2672: dual 16Gbps Gen 5 Fibre Channel
Form Factor
• Low-profile PCIe card: (6.6 inches × 2.54 inches)
• Custom form factors also available
Environment and Equipment Specifications
Temperature
• Operating: 0°C/32°F to 55°C/131°F
• Storage: –20°C/–4°F to 70°C/158°F
Humidity
• Relative (noncondensing): 10% to 90%
• Storage: 5% to 95%
Maximum Cable Distances
Rate
Multi-Mode Optic
Cable and Distance (m)
OM1 OM2 OM3 OM4
4Gbps 70 150 380 400
8Gbps 21 50 150 190
16Gbps 15 35 100 125
Agency Approvals
Safety
• US, Canada, and europe
EMI and EMC (Class A)
• US, Canada, europe, australia/New Zealand, Japan,
Korea
Ordering Information
QLE2670 (single port)
QLE2672 (dual port)
• Ships in an individually packed box with a standard-
size bracket and a spare low-profile bracket
• Ships with SR optical transceivers installed
