Fabric Specifications
Ports per Chassis
• eight 8Gb SFP ports
Port Types
• all ports are universal, auto-discovering, and self-
configuring, assuming the following states: F_Port,
FL_Port, G_Port, GL_Port, tR_Port (e_Ports not
included—single-switch environments only)
Performance Features
Fabric Port Speeds
• 2/4/8Gbps, full-duplex
• all ports auto-negotiate with slower devices
• Fabric latency: less than 0.2 ms
• Cut-through routing
Fabric Point-to-Point Bandwidth (8-port switch)
• 1,700MBps, full-duplex
Aggregate Bandwidth (8-port switch)
• 136Gbps per chassis, end-to-end
• Nonblocking architecture
Maximum Frame Sizes
• 2,148 bytes (2,112 byte payload)
Per-Port Buffering
• aSIC-embedded memory (non-shared)
Media
Supported SFP Types
• hot-pluggable, industry-standard, 3.3V SFP+ (8Gb)
transceivers
• Compatible with 4Gb and 2Gb SFPs
• Shortwave/longwave (optical), active copper
Media Transmission Ranges (2Gbps)
• Shortwave optical: 500m (1,640ft)
• Longwave optical: 10km (6.2mi)
Cable Types
• 50/62.5 micron multimode fiber optic
• 9 micron single-mode fiber optic
Fabric Management
Management Methods
• Quicktools Web applet (embedded in switch)
• CLI
• aPI, GS-4 management server (including FDMI), SNMP,
remote authentication dial in-user service (RaDIUS),
FtP, tFtP, SMI-S
• Interoperability with leading SaN management
applications
Security
• User security: user accounts, RaDIUS authentication
• Connection security: SSh (CLI), SSL (SMI-S)
• Device security: FC-SP Dh-ChaP, FC-GS-4 Ct
authentication
Access Methods
• 10/100 ethernet base-t (RJ45), serial port
(RS-232 with DB9), IPv6 support
Diagnostics
• Power-on self test (POSt)
Fabric Services
• NPIV support
• Simple name server
• hardware-based zoning
• Registered state change notification (RSCN)
• I/O StreamGuard
• automatic path selection
• FDMI support
User Interface
• LeDs, command-line console, Web utilities
Mechanical
• Optional rack-mount kit
• Front-to-back air pattern
• RohS-compliant
• Dimensions h × W × D: 43.2 Ч 432 Ч 476mm
(1.7 Ч 17 Ч 18.75in)
• Weight: 6.35kg (14lbs)
Environmental and Equipment Specifications
Operating
• temperature: 0°–40°C
• humidity (rh): 15%–80% 24-hour soak;
non-conditional, 5%–90%, 8-hour ramp
• altitude: 0–10,000 feet
• Vibration: 5–500hz, random, 0.21g rms, 10 minutes
• Shock: 4g, 11ms, 20 repetitions
Non-Operating
• temperature: –40°–70°C
• humidity: 5%–90% non-condensing
• altitude: 0–50,000 feet
• Vibration: 5–500hz, random, 2.09g rms, 10 minutes
• Shock: 30g, 13ms, trapezoidal
Electrical
• Voltage: 100–240VaC; 50–60hz
• Power load: 1a at 120VaC; 0.5a at 240VaC
• Power consumption: 60W nominal, 70W maximum
Agency Approvals—Product Safety
• US and Canada: UL/cUL, 60950-1
• europe: eN60950, CB Scheme-IeC 60950-1, Ce, tUV,
Low Voltage Directive
• Russia: GOSt R
• Demko
Agency Approvals—EMI/EMC
• Meets class a emissions and immunity requirements
for USa, Canada, europe, australia, New Zealand,
Korea, Japan
