White Paper
QLogic 10000 Series Adapter Provides
Application Benefits Through I/O Caching
Figure 4: Four Server Database Query TPS
LOCAL CACHE VERSUS REMOTE CACHE EFFICIENCY OF QLOGIC 10000
SERIES ADAPTER REMOTE ACCESS
Figure 5 identifies the configuration testing the latency difference of local
versus remote cache (where a LUN cache is located in a 10000 Series
Adapter residing on another server). Test conclusions showed a nine
percent performance impact of slightly increased latency between local
versus remote database queries.
Figure 5: Local Versus Remote Test Configuration
As shown in Figure 6, the performance benchmark measured 0 percent
cache against 30 percent local caching, and the test repeated with the
operation of caching at 30 percent in the remote configuration. No
significant difference was perceived between local cache access and
remote cache access.
Figure 6: Local Versus Remote Cache Efficiency
TEST HARDWARE AND SOFTWARE
Table 1 lists the hardware and Table 2 lists the software used for database
workload queries.
Table 1. Hardware Used for Exchange Query
Hardware
Description
Host Server
Dual 6-core Intel Xeon CPU
E5-2640 at 2.50GHz, 24 logical
processors, 32GB RAM
Host Bus Adapter
QLogic FabricCache 10000 Series
8Gb Fibre Channel Adapter
Quantity of Host Bus Adapters
per Host
1
Fabric Switch
QLogic 5800V/5802V 8Gbps Fibre
Channel Switch
Storage Array
HP EVA 6300
Drive Speed
10K
Quantity of Drives on Array
24
LUN Size
100GB × 7
RAID Type
RAID 5
