SN0058079-00 Rev. E 11/13 3
Data Sheet
10000 Series
QLogic FabricCache Adapter
host Bus Interface specifications
Bus Interfaces (Two PCIe Slots Required)
- Storage adapter: PCIe Gen2 x4 (x8 physical
connector)
- PCIe Flash daughter card: PCIe x8 power only
Host Interrupts
- INTx and MSI
Compliance
-
PCI Express Base Specification, rev. 2.0; PCI
Express Card Electromechanical Specification,
rev. 2.0;
PCI Bus Power Management Interface
Specification, rev. 1.2
Fibre Channel specifications
Throughput
- 8Gbps full-duplex line rate per port (maximum)
IOPS
- 310,000 initiator IOPS per adapter
Logins per Port
- 2,048 concurrent logins and 2,048 active exchanges
Negotiation
- 8, 4, and 2Gbps autonegotiation
Class of Service
- 2 and 3
Topology
- Switched fabric
Protocols
- FCP-3-SCSI
- FC-Tape (FCP-2)
Flash ssd specifications
Bus Interface
- PCI Express power only (x8 physical connector)
Memory Type
- Single-level cell (SLC) NAND Flash
Capacity
- 200GB or 400GB
tools and utilities
QLogic Management Tools
- QConvergeConsole, a unified GUI tool for adapter and
cache configuration and management
- Host CLI, a command line interface for adapter and
cache configuration and management
- CIM provider and vSphere™ plug-in for VMware
®
Operating Systems
- For the latest applicable operating system
information, see
http://driverdownloads.qlogic.com
physical specifications
Adapter Ports
- Dual 8Gbps Fibre Channel
Form Factor
- Storage adapter: low profile PCIe card
(6.6 inches × 2.54 inches)
- 200GB Flash daughter card: low profile PCIe card
(6.6 inches × 2.54 inches)
- 400GB Flash daughter card: low profile PCIe card
(6.6 inches × 2.54 inches)
- Interconnect cables: 2.20 inches × 0.83 inches and
3.05 inches × 0.83 inches
environment and equipment specifications
Temperature
- Operating: 0°C (32°F) to 55°C (131°F)
- Storage: –20°C (–4°F) to 70°C (158°F)
Humidity
- Relative (non-condensing) 10% to 90%
- Storage 5% to 95%
Required Airflow
- 200 linear feet per minute (LFM)
Power Consumption
- Storage adapter 18.5 watts (typical)
- PCIe Flash daughter card 21.5 watts (typical)
agency approvals
Safety
- US, Canada, and Europe
EMI and EMC (Class A)
- US, Canada, Europe, Australia, New Zealand, Japan,
and Korea
RoHS Compliance
- RoHS 6
Ordering Information
- Ships in individually packed boxes with standard size
brackets and spare low-profile brackets
- Ships with SR optical SFP transceivers installed
QLE10522 (200GB)
- Storage adapter with two 8Gbps SFPs
- 200GB SLC PCIe daughter card
- Interconnect cables
QLE10542 (400GB)
- Storage adapter with two 8Gbps SFPs
- 400GB SLC PCIe daughter card
- Interconnect cables
service sKus required with FabricCache
adapter purchase
PRF1-105
xx
C
- One year preferred, 24×7 remote technical support.
- Next business day advanced hardware replacement
PRF3-105
xx
C
- Three years preferred, 24×7 remote technical
support.
- Next business day advanced hardware replacement
Multimode Optic Cable Distance (meters)
rate
Om1
Om2
Om3
2Gbps
150
300
500
4Gbps
70
150
380
8Gbps
21
50
150
