EP8112
Dual Port 10Gbps FC over Ethernet (FCoE) to PCI Express Controller
© 2008–2009 QLogic Corporation. Specifications are subject to change without notice. All rights reserved worldwide. QLogic and the QLogic logo are registered trademarks of QLogic Corporation. All other brand and product names are trademarks or registered
trademarks of their respective owners. Information supplied by QLogic Corporation is believed to be accurate and reliable. QLogic Corporation assumes no responsibility for any errors in this brochure. QLogic Corporation reserves the right, without notice, to make
changes in product design or specifications.
CONFIDENTIAL
83812-580-00 C
2
Host Bus Interface Specifications
Bus interface
PCI Express Gen1 x8 or PCI Express Gen2 x4
•
PCI functions
Two NIC functions and two FCoE functions
•
Advanced Interrupts
MSI and MSI-X
•
Compliance
PCI Express Base Specification
•
, rev. 2.0,
PCI
Bus Power Management Interface Specification,
rev. 1.2
Ethernet Specifications
Throughput
10Gbps full duplex line rate per port
•
Topology
Any 10Gb Ethernet Network
•
Ethernet Frame
1500 byte or 9000 byte (Jumbo Frame)
•
Stateless offload
IP, TCP, and UDP checksum offloads
•
Large and Giant Send Offload (LSO, GSO)
•
Receive Side Scaling (RSS)
•
Header-Data split
•
Interrupt coalescing
•
NetQueue
•
BMC Support
SMBus and RMII (NC-SI)
•
Enhanced Ethernet
Priority-based flow control (802.1Qbb rev. 0)
•
Enhanced transmission selection (802.1Qaz
•
rev. 0)
DCBX protocol (802.1Qaz rev. 0)
•
Compliance
IEEE: 802.3ae (10Gb Ethernet) 802.1q (VLAN),
•
802.3ad (Link Aggregation), 802.1p (Priority
Encoding), 802.3x (Flow Control), 802.3ap (KX/
KX4), 802.3ak (CX4), IEEE 1149.6 (JTAG), IPv4
Specification (RFC 791), IPv6 Specification (RFC
2460), TCP/UDP Specification (RFC 793/768), ARP
Specification (RFC 826)
Fibre Channel over Ethernet (FCoE)
Specifications
Performance
250,000 IOPS per port
•
Logins
Support for 2048 concurrent logins and
•
2048 active exchanges per port
Class of service
Class 3
•
Protocols
FCP (SCSI-FCP), FC-TAPE (FCP-2)
•
Compliance
SCSI-3 Fibre Channel Protocol (SCSI-FCP) Fibre
•
Channel Tape (FC-TAPE) profile, SCSI Fibre
Channel Protocol-2 (FCP-2), Second Generation
FC Generic Services (FC-GS-2), Third Generation
FC Generic Services (FC-GS-3)
Controller Specifications
Ports
Dual XAUI/CX4/KX4 or XFI/KR
•
Memory
Integrated 1MB per port SSRAM
•
Input voltages
Core: 1.0V
•
10GbE SERDES: 1.2V, 2.5V
•
PCIe SERDES: 1.5V, 2.5V
•
I/O: 3.3V
•
Temperature
110° C maximum junction temperature
•
Airflow
System-design dependent
•
Power consumption
3.0 Watts (nominal conditions, PCIe Gen2 x4, XFI,
•
dual ports active)
Storage Temperature
-45 to 125°C
•
RoHS compliance
RoHS 6
•
Packaging
29mm x 29mm
•
783-ball (FCBGA)
•
Ball pitch 1.0 mm
•
Ordering Information
EP8112
•
Ships with minimum order quantity of
–
144 devices (36 devices per tray
× 4 trays);
increments in multiples of 36 (1 tray)
