PX2458006-00 Rev. D 07/13 3
Data Sheet
Host Bus Interface Specifications
Bus Interface
• PCI express ® (QLe246x)
• 64-bit, PCI-X™ 2.0 266Mhz DDR, compatible with
66/33Mhz PCI and 133/100/66Mhz PCI-X (QLa246x)
Memory
• 1MB SRaM per port, 1MB Flash (serial peripheral
interface [SPI]), and 2KB NVRaM (SPI)
Hardware Platforms 1
• Ia32 (x86), Ia64, IeM64t, aMD ® Opteron™
64, Oracle ® SPaRC ® , apple ® G5 (Xserve ® and
Power Mac ® )
Compliance
• PCI Express Base Specification, revision 1.0a;
PCI Express Card Electromechanical Specification,
revision 1.0; PCI Bus Power Management Interface
Specification, revision 1.1 (QLe246x)
• PCI Local Bus Specification, revision 2.3;
PCI-X Protocol addendum to the PCI Local Bus
Specification, revision 2.0a; PCI-X electrical and
Mechanical addendum (revision 2.0a) to the PCI
Local Bus Specification; PCI Bus Power Management
Interface Specification, revision 1.1; PCI hot Plug
Specification, revision 1.0 (QLa246x)
Fibre Channel Specifications
Data Rate
• 4/2/1Gbps auto-negotiation
(4.25/2.125/1.0625GBps)
Performance
• 150,000 IOPS per port
Topology
• Point-to-point (N_Port), arbitrated loop (NL_Port),
switched fabric (N_Port)
Logins
• Support for F_Port and FL_Port login:
2,048 concurrent logins and 2,048 active exchanges
per port
Class of Service
• Class 2 and 3
Protocols
• FCP (SCSI-FCP), FC-taPe (FCP-2)
1 Subject to availability of OS and hardware from respective OeMs.
Compliance
• SCSI-3 Fibre Channel Protocol (SCSI-FCP),
Fibre Channel Physical and Signaling Interface (FC-
PH), Fibre Channel 2nd Generation (FC-PH-2), Third
Generation Fibre Channel Physical and Signaling
Interface (FC-PH-3), Fibre Channel-Arbitrated Loop
(FC-AL-2), Fibre Channel Fabric Loop Attachment
Technical Report (FC-FLA), Fibre Channel-Private
Loop Direct Attach Technical Report (FC-PLDA), Fibre
Channel Tape (FC-TAPE) profile, SCSI Fibre Channel
Protocol-2 (FCP-2), Second Generation Fibre Channel
Generic Services (FC-GS-2), Third Generation Fibre
Channel Generic Services (FC-GS-3), Fibre Channel
Framing and Signaling (FC-FS)
Physical Specifications
Ports
• QLa2460: single 4Gbps Fibre Channel
• QLe2460: single 4Gbps Fibre Channel
• QLa2462: dual 4Gbps Fibre Channel
• QLe2462: dual 4Gbps Fibre Channel
• QLe2464: quad 4Gbps Fibre Channel
Form Factor
• QLe2460, QLe2462, and QLa246x:
– Low-profile PCIe ® card (6.6in. × 2.54in.)
• QLe2464:
– Full-height PCIe card (8in. × 4.376in.)
Tools and Utilities
Management Tools
• QConvergeConsole: a unified management tool
(GUI and CLI) for Fibre Channel
Device Utilities
• Utilities for Flashing boot code
• Linux ® scripting tools
Boot Support
• BIOS, extensible firmware interface (eFI), FCode
APIs
• SNIa Common hBa aPI library, SMI-S, FDMI
Operating Systems 1
• For the latest applicable operating system information,
see
http://driverdownloads.qlogic.com
Environment and Equipment Specifications
Airflow
• No airflow required
Temperature
• Operating: 0°C to 55°C (32°F to 131°F)
• Storage: – 20°C to 70°C ( – 4°F to 158°F)
Humidity
• Relative (noncondensing): 10% to 90%
• Storage: 5% to 95%
Power Consumption
• QLa2460: 6.5 watts (maximum)
• QLe2460: 5 watts (maximum)
• QLa2462: 8 watts (maximum)
• QLe2462: 6.5 watts (maximum)
• QLe2464: 16 watts (maximum)
Cable Distances
• 1Gbps: 500 meters 50/125μm fibre, 300 meters
62.5/125μm fibre
• 2Gbps: 300 meters 50/125μm fibre, 150 meters
62.5/125μm fibre
• 4Gbps: 150 meters 50/125μm fibre, 70 meters
62.5/125μm fibre
Agency Approvals—EMI and EMC
US
• FCC Class a: QLe2464
• FCC Class B: QLe2460 and QLe2462
Canada
• Class a: QLe2464
• Class B: QLe2460 and QLe2462
Europe
• 2004/108/eC/eeC eMC Directive Ce Mark, eN55022:
1998/CISPR22:1997: QLe2464 Class a, QLe2460
Class B, and QLe2462 Class B
• CISPR Class B: QLe2460 and QLe2462
• eN55024: 1998: QLe2460, QLe2462, and QLe2464
• eN61000-3-2:1995: QLe2460, QLe2462, and
QLe2464
• eN61000-3-3:1994: QLe2460, QLe2462, and
QLe2464
• eN61000-3-2: 2000 and eN61000-3-3: 2001:
QLe2460, QLe2462, and QLe2464
Japan
• Class a: QLe2464
• Class B: QLe2460 and QLe2462
Taiwan
• Class a: QLe2464
• Class B: QLe2460 and QLe2462
New Zealand and Australia
• Class a: QLe2464
• Class B: QLe2460 and QLe2462
Korea
• Korea Class a: QLe2464
• Korea Class B: QLe2460 and QLe2462
