Protek 736 Station Monitor User Manual
Page 2
W
O
T
F
E
.
M
W
W
.P
R
E
K
IR
C
O
W
O
T
F
E
.
M
W
W
.P
R
E
K
IR
C
O
W
O
T
F
E
.
M
W
W
.P
R
E
K
IR
C
O
STYLE HEIGHT WIDTH INLET OUTLET WEIGHT FLOW
LBS GPM
736 18” 18” 3”or 4”(F) 2-1/2” 45 1250
Style# 736
Seamless brass 2.5” waterway for flow up to 1,250 GPM
Corrosion resistant brass construction ideal for marine, offshore,Industrial, or other corrosive environment
Smooth internal waterway for efficient flow
360 degree horizontal and 135 degree vertical travel 90 degree above to 45 degree below
Cast brass swivel joints
Stainless steel balls in all swivels.
Stainless steel lever
Positive friction locks on both horizontal and vertical travel to hold desired position
Powder coating gives a tough corrosion resistant finish
Operating pressure of 200 PSI (14 bar)
