Style#625
Fire Fighting Equipment
OSCILLATING MONITOR
The ground oscillating monitors have sweeping water streams for attack, cooling, protection
and haz-mat situations
The water driven turbine sweeps the outlet back and forth in a smooth and powerful motion
while unmanned
The water driven turbine make the nozzles oscillating at 10, 15, or 20 degrees either side of the center
On/Off knob can stop oscillating at any point
The oscillating mechanism can be disengaged. Horizontal rotation moved manually
Elevation is adjustable between 30 degree and 60 degree unmanned. Down to 20 degree when manned
Built-in pressure gauge
Large handle makes moving easy
Carbide tips spikes for extended wear and stability
Powder coating gives corrosion resistant finish
Oscillating Speed (with straight bore tip)
Style Inlet outlet Flow Minimum Flow to Weight
Start Oscillating
625 2-1/2” 2-1/2” 500 175 28
(GPM) (GPM) Lbs
Cycles Per Minute Flow
8 175 GPM (660 LPM)
11 225 GPM (850 LPM)
22 350 GPM (1,325 LPM)
25 500 GPM (1,900 LPM)
