PROLiNK HURRICANE 8000 ADSL MODEM User Manual
Page 7
Section 2.
Hardware Installation
2.1
Hardware Configuration Overview
USB cable to PCs USB port
Main Phone Socket
Telephone
PC
Microfilter
-1
Telephone
-1 Microfilter is optional, can be purchased through dealer / manufacturer.
Microfilter is needed to:- Filter line noise;
- Prevent line noise when there are incoming/ outgoing calls;
- Prevent drop in modem connection speed.
-2 For additional phone socket which is in use and is sharing the same line, you will need to attach with an external
microfilter.
P4
Hurricane 8000
Other Phone socket
-2
