CYLINDER
SPRING PIN
SPACER
CYLINDER PIN
SPRING PIN
FIG. 4
MAIN PIVOT GREASE FITTING INSIDE PIVOT
END OF ARM WELDMENT
Figure 4
FIG. 3
BARRIER TO CYLINDER
ATTACHMENT AS SEEN
FROM FRONT
Figure 3
LIMIT SWITCH ROD ACTUATOR ABOVE PIN/SPACER AND ACTUATED WHEN CYLINDER RETRACTS
