B
A
C
D
E
A
Lip Hinge Line
B
Lip Cylinder Pin
C
Storage Prop (3 Places)
D
Hoist Cylinder Pins (2)
E
Rear Hinge Pins (3)
Figure 6
WARNING
Arrow on flow control valve
must point away from hoist
cylinder. Improper installa-
tion will allow the leveler to
free
fall which could result
in serious injury and or
property damage.
WARNING
WHEN A HYDRAULIC
CYLINDER IS EXTENDED,
IT MUST BE FULL OF
HYDRAULIC FLUID TO
SUPPORT A LOAD.
EXTENDING HYDRAULIC
CYLINDERS BY A MEANS
OTHER THAN HYDRAU-
LIC POWER CAN RESULT
IN SEVERE PERSONAL
INJURY OR DEATH.
