39 Manual No. 4111-0029
November 2009
May 2012
PARTS
Power Pack Assembly
Item Quantity Part Number Description
1 1 1431-0011 Connector-2 Screw, 3/8
2 3 1431-0086 Insulated Terminals, 16-14 AWG
3 2 2101-0017 HHCS-Grad 2-Zinc Plated, 3/8-16 UNC X 1
4 2 2101-0140 Lock Washer, 3/8
5 2 2401-0001 Grommet, 1-3/8 OD X 3/4 ID
6 1 2751-0016 J-Box Cover, 4 X 4
7 1 3051-0058 Capacitor-Motor Start, 66-77mf-330V
8 1 9301-0164 Fitting Connector Straight Thread, #4 ORB #4 JIC
9 1 9391-0040 Powerpack-PStop, 1PH-115V-1/4HP-1GPM
10 1 9391-0013 Cover-Pstop
11 1 9391-0012 Powerpack Mounting Weldment
12 REF 9904-0119 Hydraulic Hose ASM-1/4” 100R17 X 96, #4 JICF Swivel Both Ends
13 1 R513-0050 Wire, 16 GA Red X 5.00
14 2 R598-0090 Split Flex Conduit, 1-4 X 9.00
15 1 8581-0118 Coil
16 1 8581-0117 Valve
9395-0092 PPAC Complete Includes 1-16
* 9-L-000-A-K Control Box
* Hose Lengths Vary by Job
BC = Blind End of Cylinder
RC = Rod End of Cylinder
