Poweramp HM SERIES MECHANICAL - Manual (Page 37)

35 4111-0007 — June 2010
PARTS
Toe Guard/Weather Seal—Optional
Item Quantity Part Number Description
A 2 DOTH-2818 Channel, Weather Seal, 84”
B 2 DOTH-2824 T-Rubber, Weather Seal, 84”
C 2 DOTH-2820 Extrusion, Brush Weather Seal, 84”
CC 2 DOTH-2822 Brush Weather Seal, 1.58” x 84”
D 2 DOTH-2043 Cap Screw
E 4 DOTH-2207 Washer
F 1 See Chart
G 1 See Chart
H 2 DOTH-2131 Nut, Nylon Lock
J 1 See Chart
K 1 See Chart
CC
C
B
D
A
E
E
F
G
H
J
K
