PARTS
Item Quantity Part Number
Description
A
1
DFRA-____
1
Frame, Welded Assembly
DFRA-____
1
Frame, Clean Sweep, Welded Assembly (Optional)
B
1
DOTH-2555 Spring, Snubber
C
1
DOTH-2418 Hook, S.
D
1
DPLA-2128
Chain, Lip Assist Link
E
1
DOTH-2416 Link,Lap
F
1
DPLA-1218
1
Bolt, Spring Adjuster 8 foot long
1
DFRA-0323
1
Plate, Spring Tensioner 6 foot long
1
DFRA-0323
1
Plate, Spring Tensioner 8 foot long
1
DOTH-2222 Washer
G
1
DOTP-6424
1
Lift Arm, Short, 25” All 6’ long and 6’x8’ -25K
1
DOTP-6423
1
Lift Arm, Long, 27” 6’x8’ 30K to 7’x8’ 40K
H
1
9201-0006
Prop Pin and Clip
J
1
DOTH-2401 Roller Assembly, Cam
K
AR*
DOTH-____
1
Spring, Lift
L
3
DOTH-2382 Pin, Cotter, 1/4 x 2 in.
M
3
9202-0002
Pin, Rear Hinge
P
2
DOTH-2418 Hook, S
Q
1
DOTH-2423 Ring, Chain
R
1
5265-0012
1
Chain, Hold-Down Release 6 ft/10ft
1
5265-0013
1
Chain, Hold-Down Release 8 ft
S
1
DOTP-____
1
Prop, Maintenance
T
2
8432-0983
Keeper, Lip 16 inch 8’/10 (2)8432-1193 6’Long
2
8432-0984
Keeper, Lip 18 inch 8’/10’ (2)8432-1194 6’Long
2
8432-0985
Keeper, Lip 20 inch 8’/10’ (2)8432-1195 6’ Long
U
1
DOTH-2356 Pin, Clevis
V
1
DRFA-0350 Roller, Release Chain
W
1
DOTH-2375 Pin, Cotter
X
1
DOTH-2563 Hold-Down Assembly Complete, 31.5” Ratchet Bar (see page 29)6’L
DOTH-2564 Hold-Down Assembly Complete, 34.5” Ratchet Bar (see page 29)8’/10’L
Z
1
DOTH-2205 Washer
AA
1
DFRA-1205
Pin
AB
1
DOTH-2211 Washer, Float
AC
1
2101-0216
Link, Quick 1/8 inch
DFRA-0351 Roller Assy,6’ includes AD,AE,AF, and mounting brkt
DFRA-0348 Roller Assy,8’ includes AD,AE,AF, and mounting brkt
AD
1
DOTH-2061 Bolt, Shoulder 1/2 x 1-1/2
AE
1
DFRA-0349 Tube, Roller ZP
AF
1
DOTH-2137 Nut, Jam 3/8-16UNC
Frame Components
*AR = As Required
1
Provide dock leveler serial number, platform size, lip size and pit depth when calling or faxing orders.
