46 4111-0002 — January 2012 46
PARTS
Power Pack Assembly, Low Amp Draw
7.0 Amps @120 (volts consult factory)
1 Provide dock leveler serial number and type of installation when calling or faxing orders.
2 Provide dock leveler serial number, voltage, and phase when calling or faxing orders.
Item Quantity Part Number Description
A 1 0521-0007 90° Elbow, 1/4 NPT Male x 1/4 Tube
B 1 9301-0218 Breather Cap, Push In
C 2 0521-0201 90° Elbow, #8 ORB x #8-JIC Male
D 4 2101-0225 Cap Screw, 5/16-18 UNC x 3-1/2 in., Grade 5
E 1 9301-0226 O-Ring
F 1 9301-0224 Plastic Reservoir
G 1 9395-0404 Complete PPAC 115 Volt
E D
B A
C
Return Line
Pressure Line
