Asante Technologies FRIENDLYNET FS4124R - Manual (Page 5)

Standards : IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Interface: FS4116R - 16 RJ-45 ports with Auto-MDI/MDI-X
FS4124R - 24 RJ-45 ports with Auto-MDI/MDI-X
Switch
Architecture: Store and Forward
MAC FS4116R: 4K
Address: FS4124R: 4K
Buffer FS4116R: 1.5M
Memory: FS4124R: 1.5M
Nway Auto-
Negotitation: All ports
Full-Duplex/
Half-Duplex: All ports
LEDs: Power, Link/Activity, FDX/COL
Power: 100~240V AC, full range internal power supply
Physical 10.5in x 6.8in x 1.8in (W x D x H)
Dimensions: 267mm x 175 mm x 44 mm (W x D x H)
Weights: FS4116R: 1.2kg/2.65lb
FS4124R: 1.3kg/2.87lb
Operating
Temperature: 0°C to 40°C (32°F to 104°F)
Storage
Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 20% ~ 85% relative humidity, non-condensing
EMC Certification: FCC Class A, CE
Visit Asante online at www.asante.com
M
ak
ing Net
w
or
king Simpl
e
Product Specifications
