Alto-Shaam 7.14ESG Over - Manual

Due to ongoing product improvement, specifications are subject to change without notice. Printed in U.S.A. #480 C - 05/08
ITEM NO
. _______________________
COMBITHERM
®
7•14ESG
over
7•14ESG
Stacked Gas Combitherm ®
Combination Oven/Steamer
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
Phone: 262.251.3800 800.558.8744 U.S.A./ Canada Fax: 262.251.7067 800.329.8744 U.S.A Only
www.alto-shaam.com
ANSI/NSF 4
Bottom oven
controls
:
■ ■
Standard
■ ■
Deluxe
■ ■
S-Control
Top oven
controls
:
■ ■
Standard
■ ■
Deluxe
■ ■
S-Control
Standard features and accessories:
• Four (4) stainless steel shelves (each oven)
• Two (2) stainless steel side racks with
Seven (7) non-tilt pan support rails (each oven)
21-1/16" (535mm) horizontal width between rails
2-5/8" (65mm) vertical spacing between rails
• Four (4) adjustable legs
• One (1) hand-held shower with backflow preventer
(patent pending).
• One (1) flush-mounted rotary door latches with steam
venting position (each oven)
• One (1) single-point detachable temperature probe
(optional on S-Control models) (each oven)
Model 7•14ESG over
Model 7•14ESG
Short form specifications:
Provide Alto-Shaam Combitherm® Model 7•14ESG over 7•14ESG stacked flash-steam combination oven/steamer designed with
EcoSmart™ technology for reduced energy and water usage and include operational modes for steam, convection, and a combination
of steam and convection heat. Standard features to include energy efficient forced-air power burner, patented heat exchange system,
electronic ignition, patented automatic steam venting; Gold-n-Brown ™ browning function; and a self-adjusting, flush-mounted rotary
door handles with a steam venting safety stop. Control to include 2-speed fan and cool-down function. Ovens are to be constructed
of 18 gauge stainless steel, include an attached spray hose with backflow preventer, and automatic cleaning function. The ovens are
to accommodate up to 7 full-size sheet pans or 14 full-size hotel pans each, include removable door gaskets for easy replacement, and
standard right-hand door hinging. The ovens are to include the patented smoking function (only if requested with order).
Standard Control: To include removable quick-connect internal product temperature probe in the oven interior.
Deluxe Control: To include removable quick-connect internal product temperature probe in the oven interior.
and programming capability with Rapid-Touch ™ operational quick-keys.
S-Control: To include removable quick-connect internal product temperature probe in the oven interior and smoking
function as an option.
Product highlights:
• Cook by internal product temperature or time with temperature variable steam,
convection heat, or a combination of both to roast, steam, bake, or oven-fry in a single
piece of equipment.
• Provides increased food quality and expands menu options while increasing production
efficiency and speed by as much as 70% compared to conventional cooking methods.
• EcoSmart ™ technology reduces energy cost by using less electricity and water during both
normal operation and the cleaning function.
• Gold-n-Brown ™ feature provides the operator with the ability to add additional
product color.
• AutoClean ™ feature simplifies the cleaning process to a single oven function.
• Standard and Deluxe control offers 2-speed fan, a cool-down feature, additional moisture
injection, Delta-T cooking, multiple language display, and other control features.
• Enhanced safety feature includes automatic steam venting immediately before cooking
time expires. (U.S. Pat. #7,282,674)
• Flash-steam generation makes conventional steam generation obsolete:
— Eliminates steam generating boiler maintenance
— Ends boiler heating element burn-out
— Maintains steam levels without a water reservoir
• Optional patented smoking technology (U.S. Pat. 7,157,668) gives operators the unique
ability to smoke any product, hot or cold, and follow it with a non-smoked item without
any residual smoke flavor.
Series Series
Universal Stack options
■ ■
Stacked ovens with hinged doors and feet [5008347]
■ ■
Stacked ovens with recessed doors and feet [5008348]
■ ■
Stacked ovens with hinged doors and mobile base [5008795]
■ ■
Stacked ovens with recessed doors and mobile base
[contact factory for availability]
