© American Audio ® - www.AmericanAudio.us - XSP-A Series - Instruction Manual Page 15
XSP-A Series typical Speaker Set-Up
typical XSP-A Series output Set-Up
XSP-10A XSP-10A
AUX 4
AUX / IN
MADE IN CHINA
MODEL NO.: Q-3433 MKII POWER SOURCE:
115/230V~ 50/60Hz 20W
MIN MAX
TRIM OUTPUT
XLR-XLR balanced Cables
Connections are the same for 12A & 15A
Speakers
