MULTITASKER
400-0372-005 3
ABOUT YOUR MT107-303 2
MT107-303
8-Out, Twisted Pair, Single Channel
The MT107-303 is an 8 Output expansion card for
use with the MT107-104 64X64 Matrix Engine. The
MT107-303 outputs are single channel differential
outputs for use over long cable lengths. The
Twisted Pair signals from the MT107-303 may be
easily combined into a single CAT-5 cable using
ALTINEX MS8704TP adapter cables. The CAT-5
cable is then run to an ALTINEX Twisted Pair
receiver such as the DA1931CT.
Each MT107-303 connects to an output connector
on the MT107-104 Matrix Engine. Up to 8
MT107-303 cards may be connected to the engine
and each card is connected with the engine via
specially provided, high-bandwidth video cables.
As part of the MT107-104 Matrix Engine, the
MT107-303 has special built-in features. Signal
detection circuitry allows the user to determine the
presence of an output signal on any channel.
Output signals are driven by high-speed,
high-bandwidth differential amplifiers.
ALTINEX’s software and hardware allow for the
switching of any input to output combination and
prevents illegal switching combinations that may
damage components.
The latest generation of Twisted Pair devices uses
an innovative, patented technology* developed by
ALTINEX. The new signal processing technology
allows transmitting and receiving fully equalized
computer video signals, stereo, and audio signals
over long distances.
TECHNICAL SPECIFICATIONS 3
Specifications are subject to change.
See
www.altinex.com for up-to-date information.
FEATURES/
DESCRIPTION
MT107-303
GENERAL
Input
Twisted Pair Internal Box Header (1)
Output Connectors
Twisted Pair RJ-45 female (8)
Compatibility
Signal Types
ALTINEX Standard for
Twisted Pair
Video Signal
Resolutions VGA through UXGA
480p through 1080i
Recommended Max.
Cable Lengths
Note: Measurements
made using ALTINEX
low-skew cable,
CB3150PV.
VGA: 640x480@60Hz
900 ft (274 m)
XGA: 1024x768@60Hz
700 ft (213 m)
SXGA: 1280x1024@60Hz
650 ft (198 m)
UXGA: 1600x1200@60Hz
600 ft (183 m)
Table 1. MT107-303 General
MECHANICAL MT107-303
Enclosure Slots Required 1
Weight 0.4 lb (0.18 kg)
Connector Panel Black Anodized
T° Operating 10°C-50°C
T° Maximum 75°C
Humidity 90% non-condensing
MTBF (calc.) 38,000 hrs
Table 2. MT107-303 Mechanical
* US Patent 7,065,190
