Section H: Test & Adjustment Procedures 12
H: T
EST
& A
DJUSTMENT
P
ROCEDURES
NOTE: All test and adjustment procedures have been performed at the factory.
Therefore, no adjustment should be necessary.
Remove top cover panel to access the 4 push buttons, located on the control board.
The button located farthest to the right is considered Button #1 in this manual. The
buttons are then numbered from right to left which the left most button being Button
#4.
Temperature Set Point
The temperature set point is the temperature the unit will maintain the cooling block
surrounding the impinger, approximately equal to the output dew point.
Press and hold Button #1 to display the temperature set point.
Press and hold Button #3 to increase the set point.
Press and hold Button #4 to decrease the set point.
The value is automatically stored when Button #1 is released.
TEMP OUT
Connector
Temp
Out
Connector
RELAY OUT
Connector
