Section A: Specifications 5
A: S
PECIFICATIONS
Physical Description
AG-412 Model
– Vertically surface mounted system in aluminum case with removable cover.
AG-193U Model
– 19” rack mounted system in aluminum case with removable cover. 3U
panel height.
Operating Specifications
Sample Gas Flow Range 0.5- 1.5 Lpm @ 380mm Hg (15” Hg)
Sample gas humidity inlet Maximum 95% RH at room temperature, non-condensing
Dimensions 305mm x 305mm x 102mm (12” x 12” x 4”)
Weight 3.3 Kg. (7.3 lbs)
Inlet Sample Temperature 1-45°C
Maximum Inlet Pressure 1 Bar (15 psig)
Ambient Temperature Range 1° - 45°C (33° - 113°F)
Inlet Dew Point at rated flow 20°C
Outlet Sample Gas Dew Point
(based on 20C saturated inlet humidity) -1°C @ 0.5 Lpm sample flow rate
4°C @1.0 Lpm sample flow rate
10°C @ 1.5 Lpm sample flow rate
Inlet Tubing Connection ¼” tube (compression)
Outlet Tubing Connection ¼” tube (compression)
Purge (Pump) outlet Connection ¼” tube (compression)
Power Requirement 230 VAC, 50 Hz, 3A
Ambient operating humidity range 0-95% RH, non-condensing
