7 Ambi-GASS User Manual
3. Installation
3.1 Mounting
Unit should be shielded from direct rain and snow. Do not install outdoors if
temperature will fall below -10°C.
1. Arrange system on a vertical surface.
2. Place mounting feet on each corner of the enclosure with the slotted end protruding
at a 45
° angle from the enclosure.
3. Drop the mounting screw in from the top and tighten into foot.
3.2 Electrical Connection
Model # 110 VAC 220 VAC
1214 Standard Power Cord and Plug Cord with Pigtail Wires
1228 Connect power supply line to terminal block located on bottom of control
enclosure just inside 1/2" conduit hub. See Figure 4 for color coding.
G L1 N
Figure 4
