6
A flashing green LED indicates that the
adapter is sending or receiving data.
Installation
Installation the 10/100Mbps PCI bus Fast Ethernet
Card requires Hardware installation first, then BIOS
and Software installation.
Step 1, Hardware Installation
1.
Switch off the computer, unplug the power
cord, and remove the computer’s cover.
2.
Select an unused PCI bus-master slot (for
WoL use a slot PCI 2.2) and remove its
protective bracket.
3.
Carefully insert the card and press until all the
edge connectors are firmly seated inside the
slot. Then, screw the card’s bracket securely
into the PC’s chassis
4.
Install the bracket screw, which secures the
card to the cinouter chassis.
5.
Replace the computer’s cover and connect the
network cable to newly installed network
card. Reconnect the computer’s power cord
and plug it into the power outlet.
Step 2, BIOS Configuration
Due to a fault in some Plug-n-Play BIOS programs,
it happens occasionally that a newly installed
adapter is assigned an Interrupt Number which is
