American Dryer Corp. ML-175 - Manual (Page 33)

31
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 132439 1 Blower Motor Overload
2 132465 1 24 VAC Contactor
3 151001 2 #8-32 Pal Nut
4 150008 2 #6-32 x 1-1/4” Slotted Round Head Machine Screw
5 120701 1 4-Position Terminal Block
6 132434 1 D-Line Reversing Contactor
(for models mfd. as of April 20, 1999)
132448 1 K-Line Reversing Contactor - 24 VAC
(for models mfd. prior to April 20, 1999)
7 835148 1 208-240v 3ø 60 Hz Transformer (for gas models Only)
819057 208-240v 3ø 60 Hz Transformer (for steam models Only)
8 137060 1 Arc Suppressor (A.S.) Board (3)
9 137013 4 Nylon Standoff
10 152004 2 5/16-18 Hex Nut
11 121012 1 Terminal/Ground Lug
12 153002 1 5/16” Lock Washer
13 136008 2 Fuse Block/Holder
14 136057 2 1/2-Amp (Slo-Blo) Fuse ONLY
15 332346 1 Contactor/Relay Mounting Panel ONLY
819072 208-240v 3ø 60 Hz Reversing Relay Panel Assembly
For Gas Models ONLY
(includes illus. nos. 1 through 23)
819060 208-240v 3ø 60 Hz Reversing Relay Panel Assembly
For Steam Models ONLY
(includes illus. nos. 1 through 23)
16 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
17 151000 2 #6-32 Pal Nut
18 120765 2 End Stop/Bracket
19 150108 2 #8-32 x 1/2” Phillips Pan Head Machine Screw
20 150297 1 #10 x 1/2” Hex Washer TEK Screw
21 121010 1 L-70 Ground Lug
22 120768 8 Din Mounting Rail (sold by the inch)
23 132467 1 9-13-Amp Drive Motor Overload 208-240v
Microprocessor Reversing Contactor Mounting Panel Assembly
208-240v
