Installation Precautions
Do not use electro taps in the installation of this product.
Electro taps can become loose over time causing the unit to malfunction. This can also
lead to vehicle and product damage.
Be sure to use wire crimpers and the included splices for a secure connection.
Be sure that the harness is not exposed to metal.
Always wrap all connections with electrical tape.
How to use the Fittings
Strip 5mm from wire Insert sleeve over wire Bend back exposed wire Place male fitting over
exposed wire
* Use diagram below to ensure proper connection
Tighten the fitting as shown
How to use the Splices
* be sure to cover the connection with electrical tape
Clamp the wire
cover here
Clamp the wire here
Remove 5mm of the
wire cover
from
the connecting wire
Strip 10mm from
the
other
connection wire
Wrap the two
wires together Securely fasten together
other connection wire
