1 Introduction
Alpha Technologies
1.3
The Pinnacle Plus Series
1.3.1 Front Panel
These drawings are used for illustrative purposes only. See your unit for the exact location and
type of all switches and controls. The batteries are reached through this panel.
The control panel’s operation is described in Section 3.2.
Tower Mount
ON-LINE
ON
ON-BATT
BYPASS
FAULT
ON/OFF
FUNC
ENTER
Cooling Vents
(Must not be blocked)
Control Panel
Rack Mount
ON-LINE
ON
ON-BATT
BYPASS
FAULT
ON/OFF
FUNC
ENTER
Cooling Vents
(Must not be blocked)
Control Panel
Removable Battery Cover
