Diamond Products CC6550XLS-3 Speed - Manual (Page 21)

ITEM PART NO. QTY. DESCRIPTION
1 2500669 1 Hose Elbow, 3" I.D.
2 3200197 6 Hose Clamp #52
3 6010559 2 Connector Tube, 3" O.D.
4 6010983 1 Air Cleaner Hose, 3" I.D. x 12"
5 2501660 1 Hose Elbow, 3" I.D. Cobra
6 2501753 1 Hose Mount Support
7 2900592 1 Eyebolt, M10 x 50mm
8 2900325 1 Hex Nut, M10-1.5
9 2900013 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
10 2900018 1 Lock Nut, 3/8-16 Nylon
Air Intake Assembly #6010939
2
2
5
1
3
10
9
7
8
6
3
2
2
2
2
4
21
