Diamond Products CC3535 User Manual
Page 31

ITEM
PART NO.
QTY.
DESCRIPTION
1
2600052
1
Engine, 35hp Wisconsin Model W4-1770
2
2700491
1
Muffler with Clamp
3
3200151
1
Muffler Pipe Nipple 1-1/4"
4
2800386
1
Vacuum Switch
5
2500940
1
Throttle Cable Clamp
6
2900201
2
Rivet, 3/16" Dia.
7
6011005
1
Engine Base Weldment
8
2900192
4
Cap Screw, Hex Hd., 1/2-13 x 2-1/4"
9
2900058
7
Flat Washer, 1/2" SAE
10
2900026
8
Lock Nut, 1/2-13 Nylon
11
2900104
2
Tap Bolt, Hex Hd., 5/8-11 x 6"
12
2900112
2
Hex Nut, 5/8-11
13
2900446
2
Swivel Pad Nut, 5/8-11
14
6011022
1
Frame Lift
15
6010013
1
Frame Lift Brace
16
2900127
3
Flat Washer, 1/2" USS
17
2900139
2
Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
18
2900106
1
Cap Screw, Hex Hd., 1/2-13 x 2"
19
2900288
1
Cap Screw, Button Hd., 1/2-13 x 2"
20
2900013
1
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
21
2900005
1
Cap Screw, Hex Hd., 3/8-16 x 1"
22
2900018
2
Lock Nut, 3/8-16 Nylon
23
6011065
1
Oil Drain Hose Assembly
ITEM
PART NO.
QTY.
DESCRIPTION
24
3200165
1
Fitting, 3/8" M. Pipe to 3/8" Push Lock
25
6011075
1
Oil Drain Hose, 3/8" I.D. x 11"
26
3200164
1
Fitting, 3/8" F. Pipe to 3/8" Push Lock
27
3200153
1
Pipe Plug, 3/8" NPT
Engine Assembly #6011430
31
