STG3008 – FA
Technical Specifications
European Standards: EN 55011, EN 61000-6-1
General Characteristics
Operating temperature
10 °C to 50 °C
Storage temperature
0 °C to 70 °C
Dimensions (W x D x H)
220 x 170 x 60 mm
Weight 1050
g
Fuse
internal, 3.15 A slow blow
Supply voltage (external power supply)
100 - 240 VAC @ 47 to 63 Hz
Stimulus Generator
Number of stimulus generators
8
Output voltage range
-8 V to +8 V @ max. ± 20 mA
Output voltage resolution
1 mV
Rise time (10 % - 90 %) voltage
1.7 μs @ delta U = 8 V
Time lag between Sync Out and voltage output 15 ± 2 μs for continuous pulses
40 ± 5 μs for a first or a single pulse
Output current range
-1.6 mA to +1.6 mA @ max. ± 120 V compliance
voltage (between +I and -I)
Output current resolution
200 nA
Output current slope
600 μA/μs @ R
L
= 10 k
Rise time (10 % - 90 %) current, 0 - 100 μA
1.4 μs @ R
L
= 10 k
Time lag between Sync Out and current output,
0 - 100 μA
15 ± 2 μs @ R
L
= 10 k
Resolution
14 bit
Time resolution
20 μs
Output signals
Freely programmable (rectangular, ramp, sinus,
arbitrary)
Maximum frequency (rectangular waveform)
25 kHz
Memory capacity for stored waveforms
64 MB
