ADPT-NN-54
54-Electrode NeuroNexus Probe
Adapter for MPA32I Amplifiers
Side view
Important: Connect both MPA32I with the screws face down as shown in the picture above.
Otherwise, the miniature preamplifiers will not work. Important: Connect both MPA32I with the screws face down as shown in the picture above.
Otherwise, the miniature preamplifiers will not work.
Connect MPA32I No. 1 here
Connect MPA32I No. 2 here
Top
Bottom
The side with no screws is considered to be to top side of the MPA32I
Complete setup with two MPA32Is
The IN / OUT sockets 1 and 2 can be used as output connectors, for connecting single channels to other
devices, or as input connectors, for connecting other signal sources.
MPA32I No. 2
MPA32I No. 1
IN/OUT 1 IN/OUT 2
Top view
Connecting two MPA32I to the ADPT-NN-54
Warning: The device may only be used together with the MPA32I from Multi Channel Systems
MCS GmbH and the 54-channel probe from NeuroNexus, and only for the specified purpose.
Damage of the device and even fatal injuries can result from improper use.
!
