TC 01 / 02
Temperature Controller
Technical Specifications
Operating temperature 5 °C to 40 °C
Storage temperature 0 °C to 50 °C
Dimensions (W x D x H) 170 mm x 224 mm x 66 mm
Weight 1.5 kg
Supply voltage and current 24 V and 4 A
Desktop AC power adapter 85 VAC to 264 VAC @ 47 Hz to 63 Hz
Sensor type Pt100
Measuring method four wire measuring bridge
Measuring temperature range 0 °C to 105 °C
Accuracy 0.1 °C
Resolution 0.01 °C
Number of output channels 1 (TC01) / 2 (TC02)
Output voltage max. 24 V
Output current max. 2.5 A per channel
Output power max. 30 W per channel
Resistance range of heating element 5 to 100

Control range Ambient temperature (min. 5 °C) to 105 °C
Control interface USB 2.0
