6well-CC
Culture Chamber for 60-6wellMEAs
multi
channel
systems
*
The culture chamber 6well-CC for 60-6wellMEAs is suitable for the 6 well round chamber rings as well as for
6 well triangle chamber rings. To use a 60-6wellMEA in combination with the 6well-CC as a culture chamber,
please insert an O-ring inside the 6well-CC for sealing. Cover the culture chamber with foil and fix the foil with
a second O-ring. Then mount the 6well-CC on the triangle or round chamber ring on the MEA. Make sure to
place the holes exactly above the chambers of the MEA ring. Fix the culture chamber 6well-CC carefully with
a socket head screw on the 6 well ring glued on the MEA.
Important The foil to cover the 6well-CC has to be ordered separately!
For example: ALA MEA-MEM-SHEET (Set of 10 3” x 3” sheets of fluorinated ethylene-propylene
membranes for sealed MEA culture dishes). Can be ordered at Multi Channel Systems MCS GmbH.
Scope of delivery: 1 6well-CC
2 O-rings (26 x 2 mm)
1 Socket head screw (M3 x 12)
The culture chamber 6well-CC for 60-6wellMEAs
is made of teflon.
6well-CC culture chamber mounted
on a 60-6wellMEA with triangle chamber
ring and fixed with a socket head screw.
Additionally available from Multi Channel Systems MCS GmbH:
6well-CC-Set
Set of 5 MEA culture chambers for 60-6wellMEAs
Scope of delivery: 5 6well-CC
10 O-Rings
5 Socket head screws (M3 x 12)
1 Allen key
1 Box of membrane sheets
(ALA MEA-MEM-SHEET,
10 sheets of 3 x 3”)
