ME/W-SG

Signal Generator for the ME-Systems and the Wireless-System

Switch ME/W-SG on: Press the control button. Switch off: Press control button longer than two seconds.

Switch

1

Switch

2

press

Button
slowly

n times

Signal Source

OFF

OFF

1

(The ME/W-
SG is ON)

Artificial Sine Wave (1.75 mV) 0.005 Hz

Note: sine waves < 1 Hz might not be
visible because of the hardware filter
bandwidth.

2

Sine Wave 0.01 Hz

3

Sine Wave 0.03 Hz

4

Sine Wave 1.25 Hz

5

Sine Wave 12.5 Hz

ON

OFF

1

(The ME/W-
SG is ON)

(The ME/W-
SG is ON)

(The ME/W-
SG is ON)

Hippocampal Slice

EPSP

2

Hippocampal Slice

Population Spike

3

Hippocampal Neurons

Spikes

OFF

ON

1

Heart

ECG Atrium

2

Heart

ECG Ventricle

3

Cardiomyocytes

Ventricle FP

ON

ON

1

Retina

ERG with Spike

Signal Type
