Technical Specifications
Page 2 of 2
© 2014 Multi Channel Systems MCS GmbH
Interface board with connectors
Interface board
Dimensions (W x D x H)
250 mm x 83 mm x 25 mm
Weight 300
g
Front panel
4 Digital inputs
Lemo connector, EPL.00.250 NTN
4 Digital outputs
Lemo connector, EPL.00.250 NTN
2 Auxiliary channels (not in use) Lemo
connector, EPL.00.250 NTN
Rear panel
1 16 bit Digital In / Out
68-pin MCS standard connectors
1 8-Channel Analog IN
20-pin connector (2.54 mm grid), dual row standard IDC
2 Analog Inputs Lemo connector, EPL.00.250 NTN
2 USB high speed ports
USB 2.0 high speed cable (type A - mini B, 5 pin)
Power Supply
MPU 30, scope of delivery, PWR DC 0.65 x 2.75 mm
Ground
Common jack 4 mm, banana plug,
1 Audio Output
Stereo jack 3.5 mm, FFA.00.250 CTAC29
Side panel
2 Interface board to headstage
External power over serial ATA (eSATAp)
Power supply unit (MPU 30)
Input voltage
90 – 264 VAC @ 47 – 63 Hz
Output voltage
11 – 13 V
Max. Power 30
W
Mark of conformity
CE, TÜV, cUL
European standard
EN60601
Software
Operating system
Microsoft Windows ® 8.1,
Microsoft Windows ® 7 (32 or 64 bit),
XP or Vista
English and German version supported
MC_Rack program
Data acquisition and analysis software
Version 4.1.1 and higher
MC_DataTool program
Data export software
Version 2.6.3 and higher
Axon binary file (*.abf), ASCII file (*.txt),
binary file (*.raw)
Warning: The device may only be used together with MEA chips from Multi Channel
Systems MCS GmbH, and only for the specified purpose. Damage of the device and
even fatal injuries can result from improper use. Do not open the headstage or the
interface box and do not change hardware configuration as it could lead to
improper behaviour of the system.
