Multichannel Systems ADPT-NN-16 User Manual
Connecting two mpa8is to the adapter adpt-nn-16

ADPT-NN-16
16-Electrode NeuroNexus Probe
Adapter for MPA8I Amplifiers
Connecting two MPA8Is to the adapter ADPT-NN-16
Multi Channel Systems
MCS GmbH
Aspenhaustrasse 21
72770 Reutlingen
Germany
Fon +49-7121-9 09 25- 0
Fax +49-7121-9 09 25-11
[email protected]
www.multichannelsystems.com
© 2012 Multi Channel Systems MCS GmbH
Product information is subject to change
without notice.
Shown are the output pins of the adapter that are connected to the miniature preamplifiers MPAI when
looking directly at the pins. The labeled channels are the ground channels (G), the reference channel (R),
and the 8 recording channels (1 to 8) of the MPA8I. Please see the MPA8I manual for details.
Warning: The device may only be used together with the MPA8I from Multi Channel Systems
MCS GmbH and the 16-channel probe from NeuroNexus, and only for the specified purpose.
Damage of the device and even fatal injuries can result from improper use.
!
Channel assignment, output pins (connected to MPA8I)
8
7
6
5
4
3
2
1
R
G
G
8
7
6
5
4
3
2
1
R
G
G
NeuroNexus Probe
NN-ADAPTER
MPA8I No. 1
MPA8I No. 2
Side view
Connect
MPA8I No. 1 here
Connect
MPA8I No. 2 here
Important: Connect both
MPA8Is
with the black side down. Otherwise,
the preamplifiers do not work.
Important: Connect both
MPA8Is
with the black side down. Otherwise,
the preamplifiers do not work.
MPA8I No. 1
MPA8I No.2
