ASSEMBLY
One base (6) put the juice pot (5) and turn it clockwise. Put the separator (3) on the pot (5).
Put the squeezing cone (2) on the engine’s mandrel and push it. The unit is ready to operate
when the cone clamps are below the edge of the separator’s hole.
DIRECTIONS FOR USE
1. Plug the unit.
2. Half the citruses, put one of them on the squeezing cone and push it. The second hand
must hold the unit.
3. The squeezer will operate automatically. The cone will twist right or left.
4. The direction of twisting can be changed by re-pushing the cone. In this manner the
juice is extracted.
Note:
In order to change the direction of twisting cone sometimes it is necessary to push it
several times.
Do not exceed 10 minutes of constant unit operation time. After the afore-mentioned
time has lapsed switch the unit off and wait a few minutes before switching it on!
5. Lowering of the pressure on the cone automatically makes the unit switched off. Remove
the half of a fruit from the cone.
6. After extraction has been completed, remove the squeezing cone and the separator,
remove the pot turning it counterclockwise and pour the juice into glasses
CLEANING AND MAINTENANCE
1. Before you start cleaning, make sure that the device is disconnected from mains.
2. Take out a squeezer’s cone, a strainer, a container for juice and wash them in running
water. After washing, accessories should be thoroughly rinsed and dried up.
3. The case can be cleaned with a wet cloth with detergent. It cannot be submerged
into water.
4. No sharp objects, abrasive pastes, solvents or other strong chemical agents can be used
for cleaning – their use may cause damage of the device.
5. After the unit has been washed and dried, fasten the protective cover.
TECHNICAL DATA
Power supply: 220-240V 50Hz
Wattage: 30 W
A juice container – 0,6 L
Maximum time of continuous work: KB MAX = 30 sek.
Noise level: L
WA
= 67 dB
