7 midlandusa.com
Operating Controls
CB/PA
Switch
Normal /
CH9
Switch
S/RF
Display
TX LED Channel Display
Locking
Mic
Connector
On/Off
Volume
Channel
Selector
Squelch / RF
Knob
Microphone Connector: Plug in the supplied microphone to this connector.
Received signals will not be heard without the microphone.
ON/OFF Channel Buttons: This easy-to-operate control allows changing of CB
channels, either up or down.
Squelch Control: Adjust this control just until background noise disappears. If the
control is adjusted too far clockwise it may cause muting of weaker signals.
Channel Indicator: The LED displays the channel number.
TX LED: Indicator shows the unit is transmitting.
PA/CB Switch: When in PA mode, it causes your voice to operate the optional external
PA speaker. In CB mode, the microphone operates the transmitter.
Channel 9/Normal Switch: Allows you listen to emergency channel 9.
