PUMP MODEL MS-232 VER 1.0
D.NO. PART NO. DESCRIPTION QTY
50 365-026-00 WIRE NUT CONNECTOR 2
51 350-020-21 NAME PLATE 1
52 465-006-11 RIVET 4
53 525-022-21 PH.PAN HD.SCREW 2
54 660-093-00 CABLE GRIP (Order with Gland) 1
55 662-002-45 CABLE SUPPORT 1
56 660-093-00 CABLE GLAND (Order with Grip) 1
57a 260-013-66 CABLE GROMMET 4 CORE 1
57b 260-015-66 CABLE GROMMET 6 CORE 1
58 600-018-40 GLAND SPACER 1
59a 260-016-66 CABLE LEAD GROMMET 4 CORE 1
59b 260-038-66 CABLE LEAD GROMMET 6 CORE 1
60 380-010-66 "O" RING 1
61 380-007-66 "O" RING 1
62a 235-005-01 CABLE GLAND BASE 4 CORE 1
62b 235-009-49 CABLE GLAND BASE 6 CORE 1
63 380-005-66 "O" RING 1
64 650-013-21 STUD 2
65 370-006-21 HEX NUT 2
66 700-004-21 WASHER 2
67 085-009-49 CABLE CLAMP 1
68a 065-014-79 CABLE 4 CORE 14/4 S00W 50'
68b 12-4/16-3 MODYCAB 7 CORE CABLE 50'
69 525-007-40 EARTHING SCREW 1
70 430-015-01 CAP FOR VOLUTE 1
71 220-027-66 GASKET 1
72 045-003-21 HEX HD.BOLT 4
73 375-009-66 "O" RING SET 1
PORTABLE VERSION
75 405-071-01 OUTLET 4' 1
76 045-032-21 HEX HD.BOLT 2
77 700-009-21 WASHER 2
PERMANENT INSTALLATION
81a 095-015-01 4" DISCHARGE CONN. ANSI 1
81b 095-013-01 4" DISCHARGE CONN. BS 1
82 095-016-01 SLIDING BRACKET 1
83 095-023-04 UPPER GUIDE BAR HOLDER 1
