TECHNICAL SPECIFICATIONS AND PERFORMANCE
DOTCAM HR
Radiation Tolerance 1kGy (100krad) (1 x 105 rad)
Maximum Radiation Dose Rate 300Gy/h (30krad/h) (3 x 104 rad/h)
Sensor 1/3” image sensor
Resolution 350 TV lines
Min. illumination 1.0 lux f/2.0 (without LED lighting)
Signal to noise ratio > 48dB
Electronic shutter 1/60 second to 12μs (NTSC)
1/50 second to 12.5μs (PAL)
Standard lens 4mm f/5.0 (F.O.V. = 90° diagonal)
Lens for PAL Only 6mm f/2.8 (F.O.V = 54°)
Power source DC12V +/- 10%
Current consumption 110mA maximum
Diameter 29mm (1.14”)
Length (camera only) 79mm (3.1”)
Length (with mated connector) 116mm (4.6”)
Length (with connector cover) 123mm (4.8”)
Housing Stainless Steel (SS)
Lighting 6 high brightness LED’s
Sealing IP68, 60m (200’ water depth)
Operating Ambient Temperature 0°C to 60°C (32°F to 140°F)
ADDITIONAL OPTIONS
Cable, lighting, other lenses and custom configuration options available; contact your Mirion Sales Representative for details.
© Copyright 2013. All rights reserved for trademark and registered
trademark information. The above specifications may vary according
to system configuration.
Mirion Technologies Incorporated reserves the right to amend or
change the information on this sheet without prior warning.
07/13
