*C981 System Configuration generally the same as R981 (shown on
previous page)
CAMERA ouTSTATIon
Housing Material Stainless steel
operating Temperature In Air 0°C to 40°C (32°F to 104°F)
operating Temperature in Water 0°C to 50°C (32°F to 122°F)
Radiation Tolerance 100Gy [ 60 Co] (H
2
O)
10 4 Rad [ 60 Co] (H
2
O)
operating Dose Rate 100 Gy/hour (10 4 Rad/hr)
Sealing IP68 (IEC529) 60m water depth
(W.W. Fischer stainless steel
connector type SE105Z069-27)
IP66 (IEC529) fully washable
(LEMO stainless steel remote
handling cable connector type
FZJ3N318TLMY)
Maximum operating Depth 20 meters (66 ft)
Maximum Submersion Depth 60 meters (197 ft)
Camera Midpoint Connector 24-way
Cable Connection 18-way remote handling LEMO
or 12-way Fischer
pan and Tilt Speed: 6° per second
Travel: ±180° (adjustable)
Size with pan and Tilt 221mm (H) x 162mm (W) x
varying 220 to 280 (D) (8.8” x 6.5” x
varying 8.8” to 11.2”)
Weight 3.2kg (7 lbs) without lights or
microphone)
8 CHAnnEl CAMERA SySTEM Sub-RACk
nominal power Supply Input 100–120/200–240V
(auto-ranging);50/60 Hz
operation Range 85–132/170–264V (auto-ranging);
47–440 Hz
power Requirement 150VA for a fully populated
8-channel CCU
outstation Cable length 300m (656’) maximum CCU
to camera (consult IST)
operating Ambient Temperatures Fully populated, convection
cooling: 0°C to 40°C (32°F to
104°F) Up to 6 channels,
convection cooling:
0°C to 50°C (32°F to 122°F)
Fully populated, forced air cooling
at 500 liters (132 gallons)/minute:
0°C to 50°C (32°F to 122°F)
Relative Humidity 20%-75% non-condensing
Size 134mm (H) x 483mm (W) x 300mm
(D) (5.3” x 19” x 11.8”) (excluding
handles and connectors)
Weight 7kg (15.4lbs)
CCu ConnECToR TypES
AC power IEC 320 plug
(fitted with T4A fuse)
Camera Inputs (8 off) 15-way D type socket
Video outputs (8 off) 75R BNC
genlock Input 75R BNC
(with 75R termination switch)
Sync pulse output 75R BNC
Serial Control Input 9-way D type plug
Serial Control loop Through 9-way D type socket
opTIonAl ACCESSoRIES
Camera Attachments Camera allows for up to 3
attachment positions for a combi-
nation of microphone and lights
lights for underwater Up to 200W using 100W lamps
light In Air Up to 150W using sealed 50W
lamps or 75W vented lamps
lighting Sub-rack 8 Channel
Microphone For in-air use only
Microphone Sub-rack 8 Channel
CAMERA CHAnnEl pERFoRMAnCE
Horizontal Resolution 460 tvl per picture height (optical)
Illumination 1 lux
Signal to noise Ratio 48dB (weighted)
opTICS
Zoom lens 18x optical (4.1-73.8mm)
4x digital
Iris Auto F1.4
Electronic Shutter Auto 1/60 to 1/10,000 sec
NTSC 1/50 to 1/10,000 PAL
C981 compact High Resolution CCD Color Camera System*
