19
* Purchase Common Hardware Locally
REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION
NO. NO. NO. NO. NO. NO.
1 48791 1 Poly Tray 1 48791 1 Poly Tray 1 48791 1 Poly Tray 1 48791 1 Poly Tray 1 48791 1 Poly Tray
2 24908 1 Axle 2 24908 1 Axle 2 24908 1 Axle 2 24908 1 Axle 2 24908 1 Axle
3 48497 2 Wheel Assembly 3 48497 2 Wheel Assembly 3 48497 2 Wheel Assembly 3 48497 2 Wheel Assembly 3 48497 2 Wheel Assembly
4 24392 1 Tongue, Front 4 24392 1 Tongue, Front 4 24392 1 Tongue, Front 4 24392 1 Tongue, Front 4 24392 1 Tongue, Front
5 24391 1 Tongue, Rear 5 24391 1 Tongue, Rear 5 24391 1 Tongue, Rear 5 24391 1 Tongue, Rear 5 24391 1 Tongue, Rear
6 25274 1 Latch Stand Plate 6 25274 1 Latch Stand Plate 6 25274 1 Latch Stand Plate 6 25274 1 Latch Stand Plate 6 25274 1 Latch Stand Plate
7 23297 1 Latch Stand Bracket 7 23297 1 Latch Stand Bracket 7 23297 1 Latch Stand Bracket 7 23297 1 Latch Stand Bracket 7 23297 1 Latch Stand Bracket
8 48955 1 Handle Tube 8 48955 1 Handle Tube 8 48955 1 Handle Tube 8 48955 1 Handle Tube 8 48955 1 Handle Tube
9 25064 1 Wheel Support 9 25064 1 Wheel Support 9 25064 1 Wheel Support 9 25064 1 Wheel Support 9 25064 1 Wheel Support
10 62020 1 Latch Lock 10 62020 1 Latch Lock 10 62020 1 Latch Lock 10 62020 1 Latch Lock 10 62020 1 Latch Lock
11 23470 2 Bracket, Latch Mounting 11 23470 2 Bracket, Latch Mounting 11 23470 2 Bracket, Latch Mounting 11 23470 2 Bracket, Latch Mounting 11 23470 2 Bracket, Latch Mounting
12 23353 1 Hitch Pin 12 23353 1 Hitch Pin 12 23353 1 Hitch Pin 12 23353 1 Hitch Pin 12 23353 1 Hitch Pin
13 23014 1 Hitch Bracket 13 23014 1 Hitch Bracket 13 23014 1 Hitch Bracket 13 23014 1 Hitch Bracket 13 23014 1 Hitch Bracket
14 24390 1 Leg Stand Bracket 14 24390 1 Leg Stand Bracket 14 24390 1 Leg Stand Bracket 14 24390 1 Leg Stand Bracket 14 24390 1 Leg Stand Bracket
15 47029 1 Clevis Pin, 3/8" x 4" 15 47029 1 Clevis Pin, 3/8" x 4" 15 47029 1 Clevis Pin, 3/8" x 4" 15 47029 1 Clevis Pin, 3/8" x 4" 15 47029 1 Clevis Pin, 3/8" x 4"
16 45091 1 Clevis Pin 3/8" x 1" 16 45091 1 Clevis Pin 3/8" x 1" 16 45091 1 Clevis Pin 3/8" x 1" 16 45091 1 Clevis Pin 3/8" x 1" 16 45091 1 Clevis Pin 3/8" x 1"
17 HA21362 3 Hex Lock Nut (Nylock), 3/8-16 Thread * 17 HA21362 3 Hex Lock Nut (Nylock), 3/8-16 Thread * 17 HA21362 3 Hex Lock Nut (Nylock), 3/8-16 Thread * 17 HA21362 3 Hex Lock Nut (Nylock), 3/8-16 Thread * 17 HA21362 3 Hex Lock Nut (Nylock), 3/8-16 Thread *
18 43088 14 Washer, Flat 1/4" Std. Wrought 18 43088 14 Washer, Flat 1/4" Std. Wrought 18 43088 14 Washer, Flat 1/4" Std. Wrought 18 43088 14 Washer, Flat 1/4" Std. Wrought 18 43088 14 Washer, Flat 1/4" Std. Wrought
19 43001 2 Hex Bolt, 3/8-16 x 1" Lg. * 19 43001 2 Hex Bolt, 3/8-16 x 1" Lg. * 19 43001 2 Hex Bolt, 3/8-16 x 1" Lg. * 19 43001 2 Hex Bolt, 3/8-16 x 1" Lg. * 19 43001 2 Hex Bolt, 3/8-16 x 1" Lg. *
20 43177 2 Lock Washer, 1/4" * 20 43177 2 Lock Washer, 1/4" * 20 43177 2 Lock Washer, 1/4" * 20 43177 2 Lock Washer, 1/4" * 20 43177 2 Lock Washer, 1/4" *
21 43814 8 Slotted Truss Head Bolt, 5/16-18 x 3/4" Lg.* 21 43814 8 Slotted Truss Head Bolt, 5/16-18 x 3/4" Lg.* 21 43814 8 Slotted Truss Head Bolt, 5/16-18 x 3/4" Lg.* 21 43814 8 Slotted Truss Head Bolt, 5/16-18 x 3/4" Lg.* 21 43814 8 Slotted Truss Head Bolt, 5/16-18 x 3/4" Lg.*
22 46978 11 Hex Nut (Nylock), 1/4-20 22 46978 11 Hex Nut (Nylock), 1/4-20 22 46978 11 Hex Nut (Nylock), 1/4-20 22 46978 11 Hex Nut (Nylock), 1/4-20 22 46978 11 Hex Nut (Nylock), 1/4-20
23 47810 10 Hex Nut (Nylock), 5/16-18 23 47810 10 Hex Nut (Nylock), 5/16-18 23 47810 10 Hex Nut (Nylock), 5/16-18 23 47810 10 Hex Nut (Nylock), 5/16-18 23 47810 10 Hex Nut (Nylock), 5/16-18
24 43661 11 Hex Bolt, 1/4-20 x 1" * 24 43661 11 Hex Bolt, 1/4-20 x 1" * 24 43661 11 Hex Bolt, 1/4-20 x 1" * 24 43661 11 Hex Bolt, 1/4-20 x 1" * 24 43661 11 Hex Bolt, 1/4-20 x 1" *
25 43000 1 Extension Spring 25 43000 1 Extension Spring 25 43000 1 Extension Spring 25 43000 1 Extension Spring 25 43000 1 Extension Spring
26 43343 3 Hairpin, Cotter 1/8" 26 43343 3 Hairpin, Cotter 1/8" 26 43343 3 Hairpin, Cotter 1/8" 26 43343 3 Hairpin, Cotter 1/8" 26 43343 3 Hairpin, Cotter 1/8"
27 48499 2 Hub Cap 27 48499 2 Hub Cap 27 48499 2 Hub Cap 27 48499 2 Hub Cap 27 48499 2 Hub Cap
28 47038 1 Plastic Cap 28 47038 1 Plastic Cap 28 47038 1 Plastic Cap 28 47038 1 Plastic Cap 28 47038 1 Plastic Cap
29 43063 2 Hex Bolt, 5/16-18 x 1" Lg. * 29 43063 2 Hex Bolt, 5/16-18 x 1" Lg. * 29 43063 2 Hex Bolt, 5/16-18 x 1" Lg. * 29 43063 2 Hex Bolt, 5/16-18 x 1" Lg. * 29 43063 2 Hex Bolt, 5/16-18 x 1" Lg. *
30 43036 1 Hex Bolt, 3/8-16 x 4" Lg. * 30 43036 1 Hex Bolt, 3/8-16 x 4" Lg. * 30 43036 1 Hex Bolt, 3/8-16 x 4" Lg. * 30 43036 1 Hex Bolt, 3/8-16 x 4" Lg. * 30 43036 1 Hex Bolt, 3/8-16 x 4" Lg. *
31 49166 2 Detent Button 31 49166 2 Detent Button 31 49166 2 Detent Button 31 49166 2 Detent Button 31 49166 2 Detent Button
32 48840 2 Screw, 1/4"-20 x 1/2" Thread * 32 48840 2 Screw, 1/4"-20 x 1/2" Thread * 32 48840 2 Screw, 1/4"-20 x 1/2" Thread * 32 48840 2 Screw, 1/4"-20 x 1/2" Thread * 32 48840 2 Screw, 1/4"-20 x 1/2" Thread *
49167 1 Owner's Manual 49167 1 Owner's Manual 49167 1 Owner's Manual 49167 1 Owner's Manual 49167 1 Owner's Manual
REPAIR PARTS FOR POLY CART MODEL 45-0345-062
