Transformer Based Filters (TBF™) Features
About the Copier Guardian II
Common Mode Noise Filtering
Normal Mode Noise Filtering
Filters the ground noises to less than 0.5 Volts
Faulty Wiring Detection
Surge Protection
Prolonged Over Voltage Protection
Correct Harmonic Distortions (Model Dependent)
Smart Power System' patented TBF™ technology is the first application of the
differential transformer and electronic circuit to provide computer-grade
filtration.
Patented TBF™ technology protects against minor and severe spikes and
surges that comprise over 80% of power problems.
Smart Power Systems' TBF™ technology eliminates power issues that
cause disruption, degradation and destruction to electronic components.
Benefits include enhanced operation, reduced downtime and extended
operating life.
Performance Factors
Copier Guardian II is a complete power filter solution that offers comprehensive power protection for copiers, fax machines, phone systems,
and other office equipment. Our computer grade filters are power conditioners that protect copiers during any potential power problems and
eliminate spikes, surges and line noise. The Copier Guardian II is the ideal solution to provide power protection for home or office environments.
Benefits
REDUCES Error Codes
REDUCES Downtime
REDUCES "No Problem Found" Service Calls
REDUCES Paper Jams
"POVP™" prolonged over voltage protection
Low voltage spike & noise protection in
common code
Protects connected equipment against destructive over voltage.
Filters down to 0.5 Volts and stops disruptions of electronics
Exclusive Smart Technology
High voltage surge & lightning protection
Stops dangerous surges from damaging digital copiers,
fax machines and printers.
Smart Power Systems is the first and only one
to offer the following patented features:
(US Patent # 6560086)
(US Patent # 5721661)
(US Patent # 6229682)
Protects copiers against reverse polarity wiring or no ground,
making the Copier Guardian II Fail-Safe.
Cat 6 Network Protection (RJ45))Optional)
Verified by Fluke DTX1800.
• Different models are available for 120V, 208V, 15 Amp or 20 Amp.
* Tested under IEEE C62.41 Cat.A & B Ring wave
INPUT/OUTPUT
OUTPUT CURRENT
OUTPUT RECEPTACLE
INPUT CORD AND PLUG
SIZE (H x W x D) (In.)
NET WEIGHT (Lbs. / Kg.)
*SPIKE TRANSIENT LET THROUGH VOLTAGE (Common Mode)
*SPIKE TRANSIENT LET THROUGH VOLTAGE (Normal Mode)
TEL/MODEM/DSL PROTECTION
NETWORK PROTECTION
<0.5 Volts
15 or 20 Amps
<10 Volts
120V
6-15R or 6-20R 5-15R or 5-20R
5-15P or 5-20P - 6 Feet 6-15P or 6-20P - 6 Feet
RJ11
RJ45 Cat5e (Optional Cat6)
6.15 x 4.5 x 1.75
2.05 / 0.9
Specifications
1-800-882-8285
1760 Stebbins Dr. • Houston, TX 77043 • Tel:713-464-8000 Fax: • Email: [email protected] • www.smartpowersystems.com 713-984-0841
All specifications are subject to change without notice.
UL 1449 3rd. Edition Listed
LISTED
SAFETY UL 1449 3rd. Edition, UL 991, UL1283
208V
Copier Guardian II...
Smart Power
SYSTEMS
• • • • • • • • • • • • • • • •
A POWER QUALITY COMPANY
COPIER GUARDIAN TBF
Smart Ground Loop Protection
(Patent Pending)
Ground loops can cause data errors, component failures
and safety hazards.
Category 6 is a new standard for faster and more reliable
network infrastructure.
