GENERAL
Type: Twin mechanism compact disc player with wired controller.
Disc type: Standard compact discs (5 in / 12cm and 3in/8cm discs)
Dimensions: Player unit: 19"(W) x 3 15/32” (H) x 9 55/64” (D)
482mm (W) x 88mm (H) x 264mm (D) (without feet)
Control unit: 19"(W) x 5 3/4” (H) x 1 37/64” (D)
482mm (W) x 132mm (H) x 74mm (D) (without feet)
Installation: 19-inch rack mountable
Player unit: 2U / 2 rack spaces
Control unit: 3U / 3 rack spaces
Weight: Player unit: 11 lbs. / 5 kgs
Control unit: 4.5 lbs. / 2 kg
Power supply: 115/230V AC, 50/60Hz
Power consumption: 25W
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% (no condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Accessories: Connecting cord (2 sets for left and right channels)
Control cord (1.8m / 6 feet)
AUDIO SECTION
Quantization: 16 bit linear per channel
Sampling rate: 44.1 kHz at normal pitch
Over sampling rate: 8 times
D/A conversion 16 bit
Frequency response: +/- 1 dB 20 Hz to 20,000 KHz
Total harmonic distortion:* 0.02%
Signal to noise ratio:*
88 dB
Channel separation:* 80 dB
Output level: 2.0V +/- 1dB
Load impedance: 47 kohm or more
* with 20KHz low pass filter
FUNCTIONS
Variable pitch:
+/-8%, +/-12% or +/-16%
Search accuracy: 1/75 sec. (1 subcode frame)
Specifications and design are subject to change without notice for purpose of improvement.
American DJ ® AUDIO World Headquarters:
4295 Charter Street
Los Angeles, CA 90058 USA
Tel: 323-582-2650
Fax: 323-582-2610
Web: www.americandj.com
E-mail: [email protected]
DCD-PRO500 manual Ver 1.0 - 11/99
SPECIFICATIONS
American DJ
®
AUDIO • DCD-PRO500™ INSTRUCTION MANUAL • PAGE 15
