A75 Plus General Assembly
ITEM 230V 115V 100V SILVER BLACK DESCRIPTION WHERE USED QTY
A L813RC REMOTE CONTROL 1
9 E092AY E092AYB FASCIA ASSY 1
7 E829CP E830CP COVER PLATE 1
43 HA4V06S HA4V06B M4 X 6mm SCREW 4
21 5B483028 PIC CHIP + L818SW 1
17 C12126
1.25A T C12256
2.5A T C12256
2.5A T FUSE FUSE AND SPARE 2
1 E033AY REAR PANEL ASSEMBLY 1
80 E802AP DAMPING PAD (1 PER) L600 L700 (2 PER) RLY1
SEE L881AY FOR POSITIONING 4
75 E804AP BLACK FELT WASHERS BEHIND KNOBS 4
68 E805HK HEAT SINK 2
55 E806MI MAINS INSULATOR UNDER MOTHER PCB 1
3 E062AY DiVA LOW AMP & TUNER CHASSIS ASSY 1
2 E812SP SUB PANEL 1
59 E827PM SUPPORT SPACER UNDER TX 1
36 E82801 FOAM PAD RES. CAPS 1
57 E83001 TX GASKET UNDER TX 1
4 E855PM SELECTOR KNOB 1
69 E856MC HEAT SINK CLAMP 2
8 E861PM PUSH BUTTON 3
14 E863PM VOLUME KNOB 1
12 E072AY DIVA EXTENDED POWER BUTTON 1
13 E879PM FOOT 4
67 E879SL CONFIGURATION LABEL 1
15 E889PM BAS/TRB/BAL KNOB 3
79 E908MC KOOL PAD 2
16 F022 FUSEHOLDER COVER 2
5 F037 TOROID CLAMP 90MM FOR TX1 1
56 F038 RUBBER WASHER 90MM OD ON TOP OF TX 1
66 F062 FUSE CLIP PCB 1
64 F065 CABLE CLIP FOR REMOTE WIRE & TX
SCREEN 1
76 F164 DAMPING STRIP TOP OF FRONT 400MM
51 F185 SNAP-IN SPACER TX WIRES 2
52 H006 SNAP-IN SPACER PCB 1
72 HA3V06A M3 X 6 PCB'S TO SUB PANEL 7
42 HA3V10A M3 x 10mm SCREW MOTHER PCB 6
49 HA4A12B M4 X 12mm SCREW 2
47 HA4A45B M4 x 45mm SCREW BLK HEAT SINK FXGS 4
48 HA6K50A M6 x 50mm HEX BOLT TX FXG 1
40 HE6V06B No. 6 x 6mm SCREW BLK SUB-PAN, PCB, FRONT 7
41 HF4V09B No. 4 x 9mm SCREW BLK RR PAN, PHONO, SPKR TERMS,
COVERPLATE 13
46 HJ4A00A M4 NUT 2
