V. Routine Maintenance
When installed and operated according to the preceding guidelines, Mach III Clutch
products should require little or no routine maintenance. A repair kit is available which
contains all parts subject to typical wear: friction discs, springs and O-rings.
VI. Parts diagram
Repair Kit: Part number = Clutch Product Number + “-RPRK” (e.g. C5D3K-STH-RPRK)
Additional
Parts: Contact Mach III to obtain a complete listing of additional parts kits available for
your specific clutch. Please reference product number when calling or e-mailing.
Repair
services: Factory repair is available. A return materials authorization (RMA) number must
be obtained prior to sending any unit in for repair
FRICTION DISC
SLEEVE
RING GEAR
O-RING
SPRING
DRIVE HUB
BEARING
RETAINER RING
CYLINDER
PISTON
AIR SEAL
DRIVE DISC
